| Key | Part No. | Description | Spare parts Y/N | Qty |
| 1 | 4110000076362 | AXLE YD13 353 012 (153) | Y | 1 |
| 2 | 4110000076380 | O-RING 0634 313 536 49*3 | Y | 1 |
| 3 | 4110000076258 | SEALING RING 0734 401 106 | Y | 3 |
| 4 | 4012000042 | STUD GB898-M8*18-8.8 | N | 3 |
| 5 | 4013000033 | NUT GB6170-M8EpZn-8 | N | 3 |
| 6 | 4110000076270 | REGULATING SHIM 0769 120 468 | Y | 1 |
| 7 | 4110000076289 | GEAR YD13 353 002 (K4) Z=32 | Y | 1 |
| 8 | 4110000076246 | THRUST WASHER 0730 150 774 DUP | Y | 1 |
| 9 | 4110000076053 | BEARING YD13 351 007 WTB35*64*38 | Y | 1 |
| 10 | 4110000076190 | PRESS BOARD 4642 308 185 | Y | 2 |
| 11 | 4110000076324 | PISTON 4644 353 051 | Y | 1 |
| 12 | 4110000076324 | PISTON 4644 353 051 | Y | 1 |
| 13 | 4110000076352 | SPECIAL SEALING RING 0750 112 141 | Y | 2 |
| 14 | 4110000076199 | LIMIT PLATE 4644 351 094 | Y | 1 |
| 15 | 4110000076191 | LIMIT PLATE 4642 308 555 | Y | 1 |
| 16 | 4110000076353 | SEALING RING 0750 112 140 | Y | 2 |
| 17 | 4110000076251 | PRESSURED SPRING 0732 041 183 | Y | 2 |
| 18 | 4110000076189 | GUIDE RING 4642 308 083 | Y | 4 |
| 19 | 4110000076298 | RETAINING RING 0630 531 346 AV55 | Y | 2 |
| 20 | 4110000076302 | GUIDE RING 4642 308 084 | Y | 2 |
| 21 | 4110000076060 | NEEDLE BEARING 0750 115 182 35*42*20 | Y | 1 |
| 22 | 4110000076294 | FLEXIBLE RETAINING RING 0730 513 610 | Y | 1 |
| 23 | 4110000076062 | NEEDLE BEARING 0635 303 204 | Y | 1 |
| 24 | 4110000076295 | FLEXIBLE RETAINING RING 0730 513 611 | Y | 1 |
| 25 | 4110000076296 | FLEXIBLE RETAINING RING 0769 124 115 | Y | 2 |
| 26 | 4110000076247 | THRUST WASHER 0730 150 779 DUP | Y | 1 |
| 27 | 4110000076290 | GEAR YD13 353 011 (K3) Z=55 | Y | 1 |
| 28 | 4110000076322 | ROLLER SET 0750 119 048 | Y | 1 |
| 29 | 4110000076329 | CLUTCH ASSY.YD13 253 001 | Y | 1 |
| 30 | 4110000076067 | EX. FRICTIONAL DISC 0501 309 329 S=2,0 | Y | 8 |
| 31 | 4110000076069 | IN. FRICTIONAL DISC 4642 308 332 S=2,0 | Y | 3 |
| 32 | 4110000076068 | IN. FRICTIONAL DISC 4642 308 330 S=1,5 | Y | 2 |
| 33 | 4110000076107 | IN. FRICTIONAL DISC 4642 308 331 S=2.5 | Y | 1 |
| 34 | 4110000076074 | IN. FRICTIONAL DISC 0769 129 011 S=1,5/2,0/2,5 | Y | 1 |
| 35 | 4110000076067 | EX. FRICTIONAL DISC 0501 309 329 S=2,0 | Y | 8 |
| 36 | 4110000076069 | IN. FRICTIONAL DISC 4642 308 332 S=2,0 | Y | 5 |
| 37 | 4110000076107 | IN. FRICTIONAL DISC 4642 308 331 S=2.5 | Y | 1 |
| 38 | 4110000076074 | IN. FRICTIONAL DISC 0769 129 011 S=1,5/2,0/2,5 | Y | 1 |
