| Key |
Part No. |
Description |
Spare parts Y/N |
Qty |
| 1 |
29370013131 |
LINE FROM SWITCH TO MOTOR |
Y |
1 |
| 2 |
4011000461 |
BOLT GB16674-M8*16EpZn-8.8 |
N |
14 |
| 3 |
29370014291 |
BATTERY WIRE A50*350 |
Y |
1 |
| 4 |
4130000427 |
POWER SWITCH K01K18-A |
Y |
1 |
| 5 |
29370014261 |
BATTERY WIRE P50*150 |
Y |
1 |
| 6 |
4130000057 |
BATTERY 6-QW-120B |
Y |
2 |
| 7 |
29370013101 |
BATTERY CABLE |
Y |
1 |
| 8 |
29310011841 |
DIP RUBBER BAR |
Y |
2 |
| 9 |
29370015301 |
RELAY PROTECT BOX |
Y |
1 |
| 10 |
4014000024 |
SCREW GB818-M6*10EpZn-4.8 |
N |
4 |
| 11 |
4015000207 |
WASHER GB97.1-6EpZn-300HV |
N |
6 |
| 12 |
4015000035 |
WASHER GB93-6-65Mn |
N |
6 |
| 13 |
4190000020 |
CLIP LG13-ZS4*250 |
Y |
84 |
| 14 |
29370015291 |
RELAY FIXATION PLANT |
Y |
1 |
| 15 |
4130000694 |
CONTACTOR MZJ-100A/006 |
Y |
1 |
| 16 |
4014000061 |
SCREW GB818-M4*10EpZn-4.8 |
N |
2 |
| 17 |
4015000135 |
WASHER GB97.1-4EpZn-300HV |
N |
2 |
| 18 |
4015000033 |
WASHER GB93-4-65Mn |
N |
2 |
| 19 |
26370001911 |
CLAMP |
Y |
5 |
| 20 |
4130000009 |
ELECTRIC HORN DL125-24V |
Y |
1 |
| 21 |
4011000152 |
BOLT GB16674-M6*10EpZn-8.8 |
N |
2 |
| 22 |
4130000542 |
LEFT FRONT HEAD LAMP LFLDH4-24V |
Y |
1 |
| 23 |
29370014021 |
FRONT BODY WIRING HARNESS |
Y |
1 |
| 24 |
4130000543 |
RIGHT FRONT HEAD LAMP LFRDH4-24V |
Y |
1 |
| 25 |
4130000873 |
ENABLE RELAY SW030A3509-1 |
Y |
1 |
| 26 |
4014000026 |
SCREW GB818-M6*16EpZn-4.8 |
N |
2 |
| 27 |
29370015551 |
FIXED PLATE OF STARTUP RELAY |
Y |
1 |
| 28 |
4130000329 |
PRESS SWITCH 0166-40404-1-016 |
Y |
1 |
| 29 |
4130000326 |
ADJACENT SWITCH |
Y |
1 |
| 30 |
4130000278 |
DISSEPIMENT PRESSURE SWITCH310-LGK |
Y |
1 |
| 31 |
29370015031 |
BODY WIRING HARNESS |
Y |
1 |
| 32 |
4130000213 |
REAR LAMP LRTD－24V |
Y |
2 |
| 33 |
4130000544 |
REAR LARGE LAMP SPH4-1031 |
Y |
2 |
| 34 |
29370009531 |
COVER HARNESS |
Y |
1 |
| 35 |
4130000615 |
FORWARD LIGHTING QZD-1 |
Y |
4 |
| 36 |
4130000121 |
ANNUNCIATOR KSHM-12F4 |
Y |
1 |
| 37 |
29370015051 |
PANEL HARNESS ASSEMBLY |
Y |
1 |
| 38 |
29370015331 |
PANEL ASSEMBLY Y956WCH |
Y |
1 |
| 39 |
29370014681 |
INSTRUMENT DESK ASSEMBLY |
N |
1 |
| 40 |
4130000869 |
AUXILIARY RELAY 024-1Z6GD2 |
Y |
5 |
| 41 |
4014000048 |
SCREW GB818-M5*12EpZn-4.8 |
N |
5 |
| 42 |
4015000110 |
WASHER GB97.1-5EpZn-300HV |
N |
5 |
| 43 |
4015000034 |
WASHER GB93-5-65Mn |
N |
5 |
| 44 |
4130000498 |
SIDE FRAME JK931-01CKJ |
Y |
6 |
| 45 |
4130000496 |
CAP JK931-01GB |
Y |
13 |
| 46 |
4130000497 |
MIDDLE FRAME JK931-01ZKJ |
Y |
7 |
| 47 |
4130000060 |
HAND BRAKE SWITCH LA39-01Z |
Y |
1 |
