| Key | Part No. | 名称 | Description | Spare parts Y/N | Qty |
| 1 | 29340051741 | 右后扶手 | Hand rail | Y | 1 |
| 2 | 29340046232 | 右前扶手 | Hand rail | Y | 1 |
| 3 | 29340044661 | 右台架 | Platform | Y | 1 |
| 4 | 4011001508 | 螺栓GB5783-M12*40flZnyc-8.8-480 | Bolt | Y | 2 |
| 5 | 29340044751 | 空调支架 | Bracket | Y | 1 |
| 6 | 29340044921 | 挡泥板 | Rubber plate | Y | 1 |
| 7 | 29340044771 | 右梯总成 | Ladder | Y | 1 |
| 8 | 4011001249 | 螺栓GB5783-M10*30flZnyc-8.8-480 | Screw | Y | 8 |
| 9 | 4015000426 | 垫圈GB96.1-10flZnyc-300HV-480 | Washer | Y | 8 |
| 10 | 29340044931 | 压板 | Plate | Y | 1 |
| 11 | 4011001241 | 螺栓GB5783-M12*25flZnyc-8.8-480 | Screw | Y | 1 |
| 12 | 4015000427 | 垫圈GB96.1-12flZnyc-300HV-480 | Washer | Y | 9 |
| 13 | 29340044881 | 支架 | Bracket | Y | 1 |
| 14 | 4011001516 | 螺栓GB5783-M12*75flZnyc-8.8-480 | Bolt | Y | 4 |
| 15 | 4011001251 | 螺栓GB5783-M12*45flZnyc-8.8-480 | Screw | Y | 19 |
| 16 | 4043001970 | 防松套LGB331-12*24*16flZnyc-45 | Attaching sleeve | Y | 21 |
| 17 | 29340044861 | 支撑架 | Bracket | Y | 1 |
| 18 | 4015000428 | 垫圈GB97.1-12flZnyc-300HV-480 | Washer | Y | 6 |
| 19 | 4013000368 | 螺母GB6170-M12flZnyc-8-480 | Nut | Y | 6 |
| 20 | 4015000186 | 垫圈GB96.1-12EpZn-300HV | Washer | Y | 4 |
| 21 | 4011001243 | 螺栓GB5783-M12*35flZnyc-8.8-480 | Screw | Y | 4 |
