| Key |
Part No. |
名称 |
Description |
Spare parts Y/N |
Qty |
| 1 |
4041000043 |
分体法兰LGB117-310490 |
Flange half |
Y |
2 |
| 2 |
4011001300 |
螺栓GB16674.1-M10*30flZnyc-8.8-480 |
Screw |
Y |
8 |
| 3 |
4030000026 |
O形圈GB3452.1-32.5*3.55G |
O-ring |
Y |
2 |
| 4 |
29030023101 |
法兰盘面接头 |
Nipple |
Y |
1 |
| 5 |
4041001718 |
软管LGB127-010090 |
Tube lgb127-010090 |
Y |
1 |
| 6 |
29030043811 |
过渡钢管 |
Pipe |
Y |
1 |
| 7 |
4011001296 |
螺栓GB16674.1-M8*20flZnyc-8.8-480 |
Screw |
Y |
4 |
| 8 |
4041001950 |
软管LGB129-010076 |
Hose assembly |
Y |
1 |
| 9 |
26150002251 |
管夹 |
Clamp |
N |
1 |
| 10 |
4041000124 |
软管LGB128-006280 |
Hose |
Y |
1 |
| 11 |
4041001215 |
直接头LGB120-02228 |
Nipple |
Y |
1 |
| 12 |
4041000779 |
O形圈LGB168-12331 |
O-ring |
Y |
6 |
| 13 |
4041001396 |
管夹LGB122-3065 |
Clamp |
Y |
1 |
| 14 |
4013000370 |
螺母GB6170-M10flZnyc-8-480 |
Nut |
Y |
8 |
| 15 |
4011001381 |
螺栓GB16674.1-M10*35flZnyc-8.8-480 |
Screw |
Y |
2 |
| 16 |
4011001294 |
螺栓GB16674.1-M10*20flZnyc-8.8-480 |
Screw |
Y |
2 |
| 17 |
29030043751 |
支架 |
Plate |
N |
1 |
| 18 |
4030000130 |
O形圈GB3452.1-47.5*3.55G |
O-ring |
Y |
3 |
| 19 |
29030043761 |
回油钢管 |
Pipe |
N |
1 |
| 20 |
4011000337 |
螺栓GB16674-M12*60EpZn-8.8 |
Bolt |
Y |
2 |
| 21 |
4011000478 |
螺栓GB16674-M12*55EpZn-8.8 |
Bolt |
Y |
2 |
| 22 |
4041002413 |
管夹LGB169-A25*10 |
Clamp |
Y |
1 |
| 23 |
4011001297 |
螺栓GB16674.1-M8*16flZnyc-8.8-480 |
Screw |
Y |
1 |
| 24 |
29030043741 |
液压油散回油胶管 |
Hose assembly |
N |
1 |
| 25 |
4041001486 |
直接头LGB155-03036 |
Nipple |
Y |
2 |
| 26 |
4030000211 |
O形圈GB3452.1-30.0*2.65G |
O-ring |
Y |
2 |
| 27 |
4120004698 |
直通接头1CO-26-16 |
Nipple |
Y |
2 |
| 28 |
4041001006 |
组合接头LGB143-02616 |
Nipple |
Y |
2 |
| 29 |
29030042851 |
直接头UNF7 /16-M22 |
Nipple |
Y |
1 |
| 30 |
4120003299 |
O形圈8.92*1.83 |
O-ring |
Y |
1 |
| 31 |
29030039381 |
液压油散进油胶管 |
Hose assembly |
Y |
1 |
| 32 |
4041002328 |
软管LGB128-410080 |
Hose assembly |
Y |
1 |
| 33 |
4041003258 |
软管LGB128-410075 |
Hose assembly |
N |
2 |
| 34 |
4041003090 |
软管LGB128-410073 |
Hose assembly |
Y |
1 |
| 35 |
4011001299 |
螺栓GB16674.1-M10*25flZnyc-8.8-480 |
Screw |
Y |
12 |
| 36 |
29030022731 |
固定板 |
Plate |
Y |
1 |
| 37 |
4014000526 |
螺钉GB70.1-M10*70flZnyc-8.8-480 |
Screw |
Y |
2 |
| 38 |
4041000796 |
直接头LGB120-02628 |
Nipple |
Y |
5 |
| 39 |
4041000577 |
直接头LGB120-03633 |
Nipple |
Y |
1 |
| 40 |
4041001446 |
O形圈LGB168-02931 |
O-ring |
Y |
1 |
| 41 |
4120005302 |
温控风冷控制阀组 |
Valve |
Y |
1 |
| 42 |
29030042861 |
固定板 |
Plate |
Y |
1 |
| 43 |
29030022741 |
过渡块 |
Block |
Y |
2 |
| 44 |
4011001274 |
螺栓GB16674.1-M16*40flZnyc-8.8-480 |
Screw |
Y |
8 |
| 45 |
4120004418 |
压力油过滤器PLF-H240*10F |
Oil filter |
Y |
1 |
| 46 |
29030042871 |
管夹支架 |
Plate |
Y |
1 |
| 47 |
29030042881 |
橡胶管夹 |
Clamp |
Y |
2 |
| 48 |
4043003077 |
孔板LGB343-130*40*6-2*12*100R5G |
Plate |
Y |
1 |
| 49 |
4011001602 |
螺栓GB5782-M10*95flZnyc-8.8-480 |
Screw |
Y |
2 |
| 50 |
4015000433 |
垫圈GB97.1-10flZnyc-300HV-480 |
Washer |
Y |
2 |
| 51 |
4120004418001 |
压力油过滤器滤芯LH0240D010BN/HC |
Filter insert |
Y |
1 |
