| Key | Part No. | 名称 | Description | Spare parts Y/N | Qty |
| 1 | 4130001685 | 工作灯148*86-H3-24V | Lamp | Y | 2 |
| 2 | 4015000426 | 垫圈GB96.1-10flZnyc-300HV-480 | Washer | Y | 4 |
| 3 | 4130001698 | 红外夜视摄像头AE-CM10Z | Monitor | Y | 1 |
| 4 | 4014000514 | 螺钉GB818-M4*12flZnyc-4.8-480 | Screw | Y | 2 |
| 5 | 4013000371 | 螺母GB6170-M4flZnyc-8-480 | Nut | Y | 2 |
| 6 | 4015000432 | 垫圈GB97.1-4flZnyc-300HV-480 | Washer | Y | 2 |
| 7 | 29330087691 | 摄像头护罩 | Hood | N | 1 |
| 8 | 4190001839 | 扎丝LG13-ZS4*160 | Cable tie | Y | 14 |
| 9 | 29450000931 | 后罩线束 | Wiring harness | N | 1 |
| 10 | 4130000121 | 倒车蜂鸣器KSHM-12F4 | Buzzer | Y | 1 |
| 11 | 4011001297 | 螺栓GB16674.1-M8*16flZnyc-8.8-480 | Screw | Y | 2 |
| 12 | 4130001485 | 转接线 | Wiring harness | Y | 1 |
