LG958F Implement hydraulic system (3731CH) Lift arm cylinder

Key	Part No.	名称	Description	Spare parts Y/N	Qty
1	4120005999001	缸筒总成24A139210	Cylinder tube	Y	1
2	4120009098001	活塞杆总成24A116910	Piston rod	Y	1
3	4120005999003	缸盖24C101150	Cover	Y	1
4	4120005980010	衬套24S290501	Bushing	Y	1
5	4120005980008	钢丝挡圈-孔用24C090220	Retaining ring	Y	1
6	4120005999004	密封件-缓冲24H009004	Sealing ring	N	1
7	4120005999005	密封件-活塞杆24F209003	Sealing ring	N	1
8	4120008479002	挡圈-U形圈24E00902C	Retaining ring	N	1
9	4120004336016	密封件-防尘24D209002	Sealing ring	N	1
10	4120005980009	钢丝挡圈-孔用24C090240	Retaining ring	Y	1
11	4120005999008	O形圈24K11600A	O-ring	N	1
12	4120009098002	挡圈-O形圈24M11700C	O-ring	N	1
13	4120005999010	O形圈24K316701	O-ring	N	1
14	4120005999011	活塞24C102100	Piston	Y	1
15	4120005999012	密封件-活塞24P217002	Sealing ring	N	1
16	4120005999013	O形圈24K10900A	O-ring	N	1
17	4120008479003	挡圈-O形圈24M10950C	O-ring	N	1
18	4120005999015	支承环24G217021	Sealing ring	N	2
19	4120005980011	活塞背母24C103050	Nut	Y	1
20	4090000168	钢球GB308-5-GCr6	Ball	Y	1
21	4120005872008	螺钉-内六角凹端紧定24T908161	Screw	Y	1
22	4120007579004	轴套24C051050	Sleeve	Y	1
23	4120005999017	销边防尘24R308030	Sealing ring	Y	2
24	4120005999018	螺钉-内六角圆柱头24T518755	Screw	Y	12
25	4120005685012	固定座24C003020 M16	Anchorage	Y	1
26	4120009098003	密封件包24A105070S	Sealing kit	Y	1
