| KEY | PART NO. | DESCRIPTION | QTY |
| 1 | 4120000136 | HOSE JB8406-B16*2900 | 1 |
| 2 | 4120000075 | CLAMP Q/ZB251-0.5 | 4 |
| 3 | 2935000002 | CLAMP | 2 |
| 4 | 4011000560 | BOLT GB16674-M12*25EpZn-8.8 | 4 |
| 5 | 4130000413 | AIR CONDITIONER CD30L19 | 1 |
| 6 | 4011000447 | BOLT GB16674-M10*20EpZn-8.8 | 6 |
| 7 | 2935000752 | BRACKET | 1 |
| 8 | 4011000153 | BOLT GB16674-M6*16EpZn-8.8 | 2 |
| 9 | 4013000028 | NUT GB6170-M6EpZn-8 | 2 |
| 10 | 4120000363 | HOSE JB8406-B16*3200 | 1 |
| 11 | 4011000085 | BOLT GB5783-M10*35EpZn-8.8 | 6 |
| 12 | 4013000007 | NUT GB6170-M10EpZn-8 | 2 |
| 13 | 4015000025 | WASHER GB93-10-65Mn | 2 |
| 14 | 4015000162 | WASHER GB97.1-10EpZn-300HV | 2 |
| 15 | 2935000792 | MOUNTED PLATE | 1 |
