| KEY |
PART NO. |
DESCRIPTION |
QTY |
| 1 |
4013000066 |
NUT GB889.2-M33*1.5-8 |
1 |
| 2 |
2907000022 |
WASHER |
1 |
| 3 |
4030000035 |
O-RING GB3452.1-53*5.30G |
1 |
| 4 |
2907000024 |
RING SNAP |
1 |
| 5 |
2907000023 |
INPUT FLANGE |
1 |
| 6 |
4011000067 |
BOLT GB5782-M14*55EpZn-8.8 |
17 |
| 7 |
4015000027 |
WASHER GB93-14-65Mn |
7 |
| 8 |
2907000026 |
GASKET |
1 |
| 9 |
4011000186 |
BOLT GB5782-M12*55EpZn-8.8 |
1 |
| 10 |
4015000026 |
WASHER GB93-12-65Mn |
1 |
| 11 |
2907000025 |
SEALING COVER |
1 |
| 12 |
4030000049 |
OIL SEAL HG4-692-SG80*100*12 |
1 |
| 13 |
4021000030 |
BEARING GB297-31313 |
1 |
| 14 |
2907000027 |
BEARING SEAT |
1 |
| 15 |
2907000018 |
SPACER |
2 |
| 15 |
2907000019 |
SPACER |
2 |
| 15 |
2907000020 |
SPACER |
3 |
| 15 |
2907000021 |
SPACER |
3 |
| 16 |
2907000028 |
SHAFT SLEEVE |
1 |
| 17 |
2909000005 |
SLEEVE |
1 |
| 18 |
2907000015 |
ADJUSTING SHIM |
3 |
| 18 |
2907000016 |
ADJUSTING SHIM |
4 |
| 18 |
2907000017 |
ADJUSTING SHIM |
5 |
| 19 |
2909000006 |
BUSHING |
1 |
| 20 |
4021000032 |
BEARING GB297-31314 |
1 |
| 21 |
4011000494 |
BOLT M16*1.5*45EpZn-8.8 |
14 |
| 22 |
4015000098 |
WASHER GB93-16-65Mn |
14 |
| 23 |
4021000036 |
BEARING GB297-32216 |
2 |
| 24 |
2907000035 |
ADJUSTING NUT |
2 |
| 25 |
4016000124 |
PIN GB119.2-10u8*30 |
2 |
| 26 |
2907000032 |
CARRIER |
1 |
| 27 |
2907000031 |
LOCKING LEAF |
1 |
| 28 |
4013000052 |
NUT GB6173-M27*2-05 |
1 |
| 29 |
2907000030 |
BOLT |
1 |
| 30 |
2907000039 |
CAGE |
2 |
| 31 |
2907000040 |
LOCKING LEAF |
2 |
| 32 |
4015000025 |
WASHER GB93-10-65Mn |
2 |
| 33 |
4011000597 |
BOLT GB5786-M10*1*20EpZn-8.8 |
2 |
| 34 |
2907000130 |
WASHER |
4 |
| 35 |
|
|
|
| 36 |
2907000952 |
BOLT |
4 |
| 37 |
2909000007 |
SPIRAL BEVEL GEAR PINION(RIGHT) |
1 |
| 38 |
4021000027 |
BEARING GB283-NUP2307 |
1 |
| 39 |
4015000020 |
RING SNAP GB894.1-35-65Mn |
1 |
| 40 |
2907000033 |
WASHER THRUST |
4 |
| 41 |
2907000034 |
GEAR PINION |
4 |
| 42 |
2907000951 |
WASHER |
20 |
| 43 |
4013000198 |
NUT GB6176-M16*1.5-10 |
20 |
| 44 |
2907000043 |
LEFT CASE DIFF |
1 |
| 45 |
2907000038 |
WASHER THRUST |
2 |
| 46 |
2907000037 |
GEAR SIDE |
2 |
| 47 |
2907000041 |
SPIDER |
1 |
| 48 |
4041000019 |
O-RING LGB308-430*3.5 |
1 |
| 49 |
2909000008 |
LARGE SPRIAL BEVELGEAR (LEFT) |
1 |
| 50 |
2907000036 |
RIGHT CASE DIFF |
1 |
| 51 |
2907000949 |
BOLT |
8 |
| 52 |
2907000950 |
BOLT |
12 |
| 53 |
4015000098 |
WASHER GB93-16-65Mn |
22 |
| 54 |
4011000244 |
BOLT GB5786-M16*1.5*50EpZn-8.8 |
22 |
| 55 |
2907000046 |
PIN |
4 |
