| Basic configuration | |
| Engine | Weichai WP6G125E23 |
| Transmission system | Fixed shaft power shift, SDLG reinforced drive axle |
| Hydraulic system | Mechanical |
| Lift arm | Standard |
| Control valve | 2-joint valve |
| Brake system | Dual brake pedal |
| Cab | Standard |
| Heating & Cooling | Heater |
| Other configuration | Engine tachometer |
| Detailed configuration | |
| Overall dimension | |
| L*W*H | 6970*2520*3240mm |
| Wheel base | 2700mm |
| Min. ground clearance | 375mm |
| Max. dumping height | 2950mm |
| Lifting height | 3790mm |
| Dumping distance | 1050mm |
| Dumping angle | 45° |
| wheel tread | 1865mm |
| steering angle | 36° |
| horizontal crossing radius | 5945mm |
| Min. turning radius | 5120mm |
| Overall parameters | |
| Backet capacity | 1.8m3(1.5-3.0) |
| Rated load | 3000kg |
| operating weight | 10110kg |
| Max. tractive force | 96kN |
| Max. breakout force | 96kN |
| Tipping load | 60kN |
| Engine | |
| Model | WP6G125E23 |
| Type | watercooled, four-stroke, Inline |
| Rated power | 92kW |
| Rated speed | 2300r/min |
| Engine displacement | 6750ml |
| Max. torque | 500N.m |
| Emission standard | GB 20891-2007(China Phase II) |
| Min. fuel-consume ratio | 215g/kw.h |
| Transmission system | |
| Torgue converter | single-stage three-element hydraulic torque converter |
| Transmission type | Fixed shaft power shift |
| Gears | Forward 4 reverse 2 |
| Hydraulic system of working device | |
| Type | Mechanical control |
| total time | 9.0s |
| Brake system | |
| Service brake type | Air over hydraulic disc type |
| Parking brake type | Manual, caliper disc type |
| Steering system | |
| Type | Load sensing full hydraulic articulated steering |
| System pressure | 14 Mpa |
| Fill capacity | |
| Fuel | 140L |
| Hydraulic oil | 130L |
| Engine | 14L |
| Transmission | 45L |
| Drive axle | Forward 18L+ reverse 18L |
| Braking system | 4L |
