| NO. |
PART NO. |
PART NAME |
QTY |
| 1 |
ZL50G2-13408 |
门密封条 Sealing strip |
7.63M |
| 2 |
ZL50G2-13403 |
侧门 Side cover |
2 |
| 3 |
ZL50G2-13403-5 |
NBS504型机罩锁 Side lock |
2 |
| 4 |
ZL50G2-13403-4-1 |
圆钢 Round steel |
2 |
| 5 |
GB6170 M6 |
螺母M6 Nut |
2 |
| 6 |
ZL50G2-13403-4-3 |
丝套 Sleave |
2 |
| 7 |
ZL50G2-13403-4-2 |
圆钢 Round steel |
2 |
| 8 |
GB91 Φ2×16 |
开口销Φ2×16 Cotter pin |
8 |
| 9 |
ZL50G2-13407-3 |
板 Board |
4 |
| 10 |
ZL50G2-13407-1 |
板 Board |
2 |
| 11 |
ZL50G2-13414 |
螺柱 Bolt |
6 |
| 12 |
GB95 8 |
垫圈8 Washer |
6 |
| 13 |
GB6170 M8 |
螺母M8 Nut |
10 |
| 14 |
GB93 8 |
弹垫8 Spring washer |
10 |
| 15 |
ZL50G2-13402-11 |
挡板 Apron |
2 |
| 16 |
GB5783 M12×25 |
螺栓M12×25 Bolt |
32 |
| 17 |
ZL50G2-13410 |
气弹簧 Pneumatic spring |
2 |
| 18 |
ZL50G2-13406 |
铰链 Hinge |
4 |
| 19 |
GB95 12 |
垫圈12 Washer |
32 |
| 20 |
GB93 12 |
弹垫12 Spring washer |
32 |
| 21 |
GB5783 M12×30 |
螺栓M12×30 Bolt |
8 |
| 22 |
ZL50G2-13402-12 |
挡板 Apron |
2 |
| 23 |
GB5783 M10×30 |
螺栓M10×30 Bolt |
19 |
| 24 |
GB93 10 |
弹垫10 Spring washer |
23 |
| 25 |
GB6170 M10 |
螺母M10 Nut |
8 |
| 26 |
GB96 16 |
垫圈16 Washer |
6 |
| 27 |
GB93 16 |
弹垫16 Spring washer |
6 |
| 28 |
GB5783 M16×35 |
螺栓M16×35 Bolt |
6 |
| 29 |
GB6170 M12 |
螺母M12 Nut |
4 |
| 30 |
ZL50G2-13404 |
扶手 Hand rail |
2 |
| 31 |
ZL50G2-13402 |
中罩(配潍柴) Mid-hood (for WEICHAI) |
1 |
|
DG957A-13402 |
中罩(配上柴) Mid-hood (for SHANGCHAI) |
1 |
|
DG957B-13402 |
中罩(配康明斯) Mid-hood (for CUMMINS) |
1 |
