SL50W FIG.42 MAIN TRANSMISSION ASSEMBLY

NO.	PART NO.	PART NAME	QTY
0	50M.01	Main transimission assembly	1
1	50M.01-01	Locknut	1
2	50M.01-02	Washer	1
3	50M.01-24	O seal ring	1
4	50M.01.01-01	Flange	1
5	GB5785 M12×1.5×55	Bolt	1
6	GB93 12	Washer	1
7	GB13871 FB80×100×10	Oil seal	1
8	GB13871 B80×100×10	Oil seal	1
9	50M.01-03	Sealing gland	1
10	GB297 31313	Bearing	1
11	50M.01-04	Bearing bushing	1
12	50M.01-05	Adjusting washer	1
13	50M.01-06	Shaft bushing	1
14	GB297 31314	Bearing	1
15	50M.01-23	Adjusting washer	1
16	50M.01-20	Adjusting nut	2
17	Inch 47686/47620A	Bearing	2
18	50M.01(1)7	Differential bolt	8
19	50M.01(1)2	Nut	12
20	50M.01(1)1B	Differential cage	1
21	50M.01(1)4A/B	Driven bevel gear	1
22	50M.01(1)3	Bolt	12
23	50L.01(1)1	Washer for bevel gear	4
24	50L.01(1)9	Differential crossing	1
25	50M.01(1)6	Bevel gear	4
26	50M.01(1)9	Bearing seat	2
27	50M.01(1)0	Bolt for main reductor	4
28	404319B	Lock plate	2
29	GB93 10	Washer	2
30	GB32.2 M10×1×20	Bolt	2
31	Φ1.5X450	Iron wire	2
32	50M.01(1)8	Nut	8
33	50M.01-21	Differential cage	1
34	50M.01-09B	Thrust washer	2
35	50M.01-22	Axle shaft gear	2
36	50M.01-08	Differential cage	1
37	50L.01.03	Bolt	1
38	50L.01-23	Lock plate	1
39	GB6173 M27×2	Nut	1
40	NJ2307ENVX3	Bearing	1
41	GB305 90/96.5	Stop ring	1
42	50M.01-07A/B	Driving bevel gear	1
43	GB93 14	Washer	7
44	GB5785 M14×1.5×55	Bolt	7
