| NO. | PART NO. | PART NAME | QTY |
| 1 | ZL50G2-05009 | Radiator oil-out joint | 1 |
| 2 | ZL50FIII-06008A | Oil suction joint assy. | 1 |
| 3 | ZL50FIII-06009C | Oil return joint assy. | 1 |
| 4 | ZL50G3-06020 | Hose | 1 |
| 5 | ZL50G3-06021A | Oil-out tube,work pump | 1 |
| 6 | ZL50G2-06024B | Tube clip I | 1 |
| 7 | ZL50G2-06025A | Oil-in tube,work valve II | 1 |
| 8 | ZL50G2-06026C | Oil return tube,work valve I | 1 |
| 9 | ZL50FIII-06035 | Hose | 1 |
| 10 | ZL50FIII-06036 | Hose | 1 |
| 11 | ZL50FIII-06037 | Radiator oil-in joint | 1 |
| 12 | ZL50FIII-06037A | Radiator oil-in joint(forZL60GT-1C) | 1 |
| 13 | ZL50FIII-06038A | Radiator oil-out joint(for ZL60GT-1C) | 1 |
| 14 | ZL50FIII-06039 | Bracket | 1 |
| 15 | ZL50G2-06039 | Fixed plate | 1 |
| 16 | ZL50FIII-06040 | Oil-way board | 1 |
| 17 | ZL50FIII-06041 | Metal tube assy. | 1 |
| 18 | ZL50G3-06046 | Oil suction joint,work pump | 1 |
| 19 | ZL50G2-06052B | Tube clip II | 1 |
| 20 | ZL50G2-06053 | Rubber mat | 1 |
| 21 | DG956W-06200 | Engine oil tank assy. | 1 |
| (1) | LFS1 1/4′28LA | Flange joint | 2 |
| (2) | GB5783 M12×35 | Bolt | 4 |
| (3) | 51H-24 | Flange | 1 |
| (4) | GB3452.2 47.5×3.55 | O-ring | 1 |
| (5) | CBGj3100A | Gear pump | 1 |
| (6) | JB1000 M14×1.5 | Plug screw | 1 |
| (7) | JB982 14 | Combined washer | 1 |
| (8) | GB93 12 | Spring washer | 14 |
| (9) | GB5783 M12×25 | Bolt | 2 |
| (10) | GB5781 M10×20 | Bolt | 3 |
| (11) | GB6170 M12 | Nut | 8 |
| (12) | GB898 A M12×35 | Double-screw bolt | 4 |
| (13) | GB3452.2 37.5×3.55 | O-ring | 6 |
| (14) | 51H-20 | Flange | 6 |
| (15) | GB3618.1 57～62 | Clamp | 4 |
| (16) | GB1235 65×3.1 | O-ring | 2 |
| (17) | GB5783 M10×30 | Bolt | 24 |
| (18) | JH100 25I-1190 | Hose assembly | 1 |
| (19) | GB93 10 | Spring washer | 32 |
| (20) | GB5780 M10×55 | Bolt | 4 |
| (21) | GB93 10 | Spring washer | 12 |
| (22) | GB5781 M8×20 | Bolt | 12 |
| (23) | JH100 25I-2250 | Hose assembly | 1 |
| (24) | JB982 30 | Combined washer | 2 |
| (25) | JB982 27 | Combined washer | 2 |
| (26) | GB5781 M10×40 | Bolt | 1 |
| (27) | GB97.1 10 | Washer | 2 |
| (28) | GB3618.1 43～48 | Clamp | 8 |
| (29) | GB3452.2 43.7×3.55 | O-ring | 1 |
| (30) | GB5783 M12×30 | Bolt | 4 |
