Description
|
Unit
|
Parameter value
|
|
Rated operating load
|
kg
|
3000
|
|
Bucket capacity
|
m³
|
1.5~2.5
|
|
Machine weight
|
kg
|
10600±200
|
|
Dump clearance at maximum lift
|
mm
|
2770~3260
|
|
Reach at maximum lift
|
mm
|
1010~1210
|
|
Wheelbase
|
mm
|
2600
|
|
Tread
|
mm
|
1850
|
|
Height of hinge at maximum lift height
|
mm
|
3830
|
|
Working height(fully lifted)
|
mm
|
4870
|
|
Max. breakout force
|
kN
|
130
|
|
Max. horsepower
|
kN
|
95
|
|
Hydraulic cycle time-raise
|
s
|
5.5
|
|
Total hydraulic cycle time
|
s
|
10
|
|
Min. turning radius over tires
|
mm
|
5165
|
|
Articulation angle
|
°
|
35±1
|
|
Gradeability
|
°
|
28
|
|
Tire size
|
17.5-25-12PR
|
|
|
Overall machine dimension L×W×H
|
mm
|
7050×2482×3118
|
|
Model
|
WP6G125E22
|
|
|
Emission standards
|
Emission 2
|
|
|
Rated Power/Speed
|
kW/rpm
|
92/2200
|
|
Fuel Tank
|
L
|
170
|
|
Hydraulic Tank
|
L
|
170
|
