| ltem | Parameters | Unit | |
| Rated load | 5000 | kg | |
| Rated bucket capacity | 3 | m³ | |
| Total weight | 17500 | kg | |
| Dumping height(from ground to main blade plste) | 3090 | mm | |
| Dumping distance(from the front wheel to main blade plate) | 1130 | mm | |
| Maximum breakout force | 170 | KN | |
| Max.tractive force | 165 | KN | |
| Lifting time of swing arm | ≤6.5 | s | |
| Total cycling time | ≤11 | s | |
| Minimum turning radius(outer edge of bucket) | 7300 | mm | |
| Minimum turning radius(tire center) | 6400 | mm | |
| Articulated angle | 35 | ° | |
| Gradeability | 30 | ° | |
| tire size | 23.5-25 | ||
| Overall demension of machine(L×W×H) | 8165×3016×3485 | mm | |
| Engine model | WD10G220E23 | ||
| Rated power/rotate speed | 162/2000 | kW/r/min | |
| Travel speed | Gear I(F/R) | 0~11.5/0~16.5 | km/h |
| Gear II(F) | 0~38 | km/h | |
