Operating weight
|
16200kg
|
|
Standard bucket capacity
|
2.7m³
|
|
Rated load
|
5000kg
|
|
Max. climbing angle
|
30 degree
|
|
Standard dumping height
|
3100mm
|
|
Max. dumping height (when equipped with a high dumping arm)
|
3500mm
|
|
Dumping reach
|
1200mm
|
|
Overall dimension
|
7620*2990*3295mm
|
|
Torque converter
|
Single-phase 4-element, Twin-turbine hydraulic torque converter
|
|
Transmission
|
Planetary hydraulic shift
|
|
Model
|
Weichai WD10G220E21
|
|
Type
|
4-stroke, inline diesel engine, turbo-charged direct-injection
|
|
Qty of cylinders-bore/stroke
|
6-126x130mm
|
|
Rated power
|
162KW
|
|
Rated speed
|
2200r/min
|
