| NO. | PART NO. | PART NAME | QTY |
| 1 | 1455-30-03000 | Cover board | 1 |
| 2 | 1455-30Y-03000 | Tipping cylinder rear shaft | 1 |
| 3 | GB5783—M8X20 | Bolt | 6 |
| 4 | GB93-8 | Washer | 6 |
| 5 | 07303-01016 | Sealing washer | 16 |
| 6 | 1455-30-00002 | Link bolt | 8 |
| 7 | 1455-30-00001 | Washer | 5 |
| 8 | GB5783-M16X30-1 | Bolt | 7 |
| 9 | 1455-30-27000 | Movable arm rear shaft (L) | 1 |
| 10 | 1457-30-00021 | Adjusting gasket | 6 |
| 11 | 1455-30-06000 | Lifting cylinder rear shaft (L) | 1 |
| 12 | 07020-01021 | Oil cup | 9 |
| 13 | GB93-16 | Washer | 3 |
| 14 | 1455-30-12000 | Lubricating pipe(LH) | 1 |
| 15 | 1455-30-07000 | Steering cylinder front shaft | 2 |
| 16 | 1455-30-09000 | Lubricating pipe(RH) | 1 |
| 17 | GB5783-M10X40 | Bolt | 2 |
| 18 | GB93-10 | Washer | 2 |
| 19 | 1455-300-08000 | Grease tube | 2 |
| 20 | 1456-30E-02000 | Grease tube | 1 |
| 21 | 1455-30E-01000 | Front frame | 1 |
| 22 | 1455-30-00017 | Clip | 3 |
| 23 | GB93-6 | Washer | 6 |
| 24 | GB818-M6X10 | Screw | 6 |
| 25 | 1455-81-00013 | Adjusting gasket | 9 |
| 26 | 1455-30-05000 | Movable arm rear shaft® | 1 |
| 27 | 1455-30-26000 | Lifting cylinder rear shaft ® | 1 |
| 28 | 1455-30-00009 | Press board | 1 |
| 29 | 1455-30-00006 | Bearing cover | 1 |
| 30 | 1455-30-00015 | Adjusting gasket | 6 |
| 31 | 1455-30-10000 | Grease tube | 1 |
| 32 | 1455-30-00018 | Link bolt | 1 |
| 33 | GB9877.1-B80X100X10 | Seal ring | 1 |
| 34 | GB297-7514E | Bearing | 2 |
| 35 | 1455-30-00003 | Adjusting gasket | 1 |
| 36 | 1455-30-00004 | Upper link shaft | 1 |
| 37 | GB9877.1-B85X110X12 | Seal ring | 1 |
| 38 | 1455-30-00008 | Sleeve | 1 |
| 39 | 1455-30-00007 | Bearing base | 1 |
| 40 | 1455-30-00010 | Pan | 1 |
| 41 | 1455-30-00011 | Slotted nut | 1 |
| 42 | 04050-16390 | Cotter pin | 1 |
| 43 | 1455-30-00016 | Base | 1 |
| 44 | 1455-30-11000 | Lower jointed shaft assy. | 1 |
| 45 | 1455-30-00012 | Lower jointed bearing cover | 1 |
| 46 | 1455-30-00013 | Pad | 1 |
| 47 | 1455-30-00031 | Dust ring | 2 |
| 48 | 1455-30-28000 | Radial joint bearing | 1 |
| 49 | 1455-30-00032 | Adjusting washer | 1 |
| 50 | GB5782-M12X110-1 | Bolt | 6 |
| 51 | 1455-30-00005 | Washer | 6 |
| 52 | GB5783-M16X40-1 | Bolt | 4 |
| 53 | 1455-30-00014 | Washer | 4 |
| 54 | GB5783-M16X35-1 | Bolt | 1 |
| 55 | GB97.1-16 | Washer | 1 |
| 56 | GB5783-M12X80-1 | Bolt | 8 |
| 57 | GB93-12 | Washer | 8 |
