| MODEL | LG920E | CDM833/LG833N | CDM843 | LG855N |
| Operating weight (kg) | 3780 | 10300 | 13000 | 16800kg |
| Rated loading weight (kg) | 900 | 3000 | 4000 | 5000 |
| Rated bucket capacity (m3) | 0.6 | 1.7 | 2.3 | 3.0 |
| Engine model | Quanchai | WEICHAI | WEICHAI | WEICHAI |
| Rated power (kw/rpm) | 33.1/2300 | 92/2200 | 129/2200 | 162/2200 |
| Travel speed (km/h) | 0-21 | 0-36 | 0-36 | 0-36 |
| Max. traction force (Kn) | / | 97 | 120 | 155 |
| Max. break-out force (Kn) | / | 105 | 115 | 170 |
| Tire | 16/70-16 | / | / | / |
| Overall Dimensions (LxWxH) | 5805*1880*2850 | 7200*2500*3180 | 7270*2800*3300 | 8015*3000*3380 |
| Dumping clearance(mm) | / | 2904 | 2915 | 3080 |
| Dumping reaching(mm) | / | 1095 | 1110 | 1276 |
